This grip’s mulit-weave construction (triple, double, single) is ideal for heavy loads. MU cable grips are color coded for ease of identification. Perfect for stringing overhead transmission and distribution lines and heavy-load pulls of any kind. Use with bare or insulated cable, conductor or wire. The flexible eye connects with Slingco line pulling swivels for trouble free pulling applications. Made of Galvanized Steel.
Note: Not recommended for pulling static or guy wire. Use High Strength ‘A-Type’ grip when pulling static or guy wire.
| Slingco Part No. | Color Code | Range (mm) | Lattice Length (mm) | Approx. Break Load (kg) |
|---|---|---|---|---|
| ZCS1710 | Dark Green | 6-12 | 787 | 3,170 |
| ZCS1711 | Brown | 12-19 | 1,143 | 4,760 |
| ZCS1712 | Light Blue | 19-25 | 1,092 | 6,395 |
| ZCS1713 | Gold | 25-32 | 1,651 | 11,340 |
| ZCS1714 | Black | 32-38 | 1,499 | 14,065 |
| ZCS1715 | Red | 38-44 | 2,083 | 14,065 |
| ZCS1716 | Dark Blue | 44-57 | 2,083 | 22,230 |
| ZCS1750 | Yellow | 51-63 | 1,829 | 22,230 |
| ZCS1751 | Orange | 63-76 | 1,829 | 22,230 |
| ZCS1752 | Aluminum | 76-89 | 1,880 | 22,230 |
| ZCS1753 | Light Green | 89-102 | 1,930 | 22,230 |
| Slingco Part No. | Color Code | Range (in) | Lattice Length (in) | Approx. Break Load (lb) |
|---|---|---|---|---|
| ZCS1710 | Dark Green | 0.25 - 0.50 | 31 | 7,000 |
| ZCS1711 | Brown | 0.50 - 0.75 | 45 | 10,500 |
| ZCS1712 | Light Blue | 0.75 -1.00 | 43 | 14,100 |
| ZCS1713 | Gold | 1.00 - 1.25 | 65 | 25,000 |
| ZCS1714 | Black | 1.25 - 1.50 | 59 | 31,000 |
| ZCS1715 | Red | 1.50 - 1.75 | 82 | 31,000 |
| ZCS1716 | Dark Blue | 1.75 - 2.25 | 82 | 49,000 |
| ZCS1750 | Yellow | 2.00 - 2.50 | 72 | 49,000 |
| ZCS1751 | Orange | 2.50 - 3.00 | 72 | 49,000 |
| ZCS1752 | Aluminum | 3.00 - 3.50 | 74 | 49,000 |
| ZCS1753 | Light Green | 3.50 - 4.00 | 76 | 49,000 |
| Code Word | Cable | Cable OD* (in) | Slingco Cable Grip | Size Range (in) | Break Load (lb) | Recommended Swivel |
|---|---|---|---|---|---|---|
| Raven | 1/0 | 0.398 | ZCS1800 | 0.38-0.63 | 14,000 | ZSW2093 |
| Raven | 1/0 | 0.398 | ZCS3020 | 0.25-0.40 | 10,000 | ZSW2092 |
| Raven | 1/0 | 0.398 | ZCS1799 | 0.19-0.40 | 7,000 | ZSW2092 |
| Raven | 1/0 | 0.398 | ZCS1710 | 0.25-0.50 | 7,000 | ZSW2092 |
| Quail | 2/0 | 0.447 | ZCS3522 | 0.44-0.63 | 20,000 | ZSW2094 |
| Pigeon | 3/0 | 0.502 | ZCS1800 | 0.38-0.63 | 14,000 | ZSW2092 |
| Penguin | 4/0 | 0.563 | ZCS1710 | 0.25-0.50 | 7,000 | ZSW2092 |
| Merlin; Trogon; Woodcock; Widgeon; Linnet; Driole | 336.4 | 0.684-0.741 | ZCS5543 | 0.63-0.88 | 30,700 | ZSW2096 |
| Merlin; Trogon; Woodcock; Widgeon; Linnet; Driole | 336.4 | 0.684-0.741 | ZCS1801 | 0.63-0.88 | 20,000 | ZSW2094 |
| Merlin; Trogon; Woodcock; Widgeon; Linnet; Driole | 336.4 | 0.684-0.741 | ZCS1711 | 0.50-0.75 | 10,500 | ZSW2092 |
| Chickadee | 397.5 | 0.743 | ZCS5543 | 0.63-0.88 | 30,700 | ZSW2096 |
| Chickadee | 397.5 | 0.743 | ZCS1801 | 0.63-0.88 | 20,000 | ZSW2094 |
| Chicadee | 397.5 | 0.743 | ZCS1711 | 0.50-0.75 | 10,500 | ZSW2092 |
| Ptarmigan; Stork; Brant; Ibis; Lark | 397.5 | 0.752-0.806 | ZCS5543 | 0.63-0.88 | 30,700 | ZSW2096 |
| Ptarmigan; Stork; Brant; Ibis; Lark | 397.5 | 0.752-0.806 | ZCS1801 | 0.63-0.88 | 20,000 | ZSW2094 |
| Ptarmigan; Stork; Brant; Ibis; Lark | 397.5 | 0.752-0.806 | ZCS1712 | 0.75-1.00 | 14,100 | ZSW2093 |
| Pelican; Tailorbird; Toucan; Hawk | 477 | 0.814-0.858 | ZCS5543 | 0.63-0.88 | 30,700 | ZSW2096 |
| Pelican; Tailorbird; Toucan; Hawk | 477 | 0.814-0.858 | ZCS1801 | 0.63-0.88 | 20,000 | ZSW2094 |
| Pelican; Tailorbird; Toucan; Hawk | 477 | 0.814-0.858 | ZCS1712 | 0.75-1.00 | 14,100 | ZSW2093 |
| Osprey; Parakeet; Dove; Eagle | 556.5 | 0.88-0.953 | ZCS1802 | 0.88-1.13 | 30,700 | ZSW2096 |
| Osprey; Parakeet; Dove; Eagle | 556.5 | 0.88-0.953 | ZCS1712 | 0.75-1.00 | 14,100 | ZSW2093 |
