Line Pulling Swivels - Standard End

Features and benefits

  • Releases torsion
  • Prevents damage to cable or grip
  • Suitable for underground or overhead applications
  • Straight line pulling only

Swivels designed for use in stringing high tension wires for electrical transmission and distribution. Swivels are important in pulling when the lines develop torsion during the installation. This torsion must be released. Use of a swivel will release torque and prevent it from reaching dangerous levels, which can cause damage to the cable or grip.

Slingco also offers a ‘bull nose’ style swivel designed for underground and overhead applications.

All swivels are stringently quality tested and inspected to ensure optimum performance and reliability.

Swivel_Standard_End
Slingco Part No. Safe Working Load - 3:1 FOS (lb) Safe Working Load - 5:1 FOS (lb) A Length (in) Ø B (in) C (in) Ø D Pin (in) E Recess (in) Weight (lb)
ZSW20912,2501,3503.390.870.390.310.390.43
ZSW20923,5002,1003.980.980.430.390.430.56
ZSW20935,0003,0004.961.26.0550.390.551.13
ZSW20947,0004,2005.221.380.550.50.541.44
ZSW209610,0006,0006.11.620.710.630.652.35
ZSW209715,0009,0007.342.090.790.710.834.59

Note:
3:1 factor of safety and 5:1 factor of safety provided for reference only

A note about dimensions and tolerances

Slingco Part No. Safe Working Load - 3:1 (kN) Safe Working Load - 5:1 (kN) Ø A (mm) B Length (mm) C Slot Width (mm) D Pin Ø (mm) Ø E Recess (mm) Weight (kg)
ZSW20911062285.6108100.19
ZSW209215.59.325101.11110110.25
ZSW20932213.2321261410140.51
ZSW209431.118.735132.71412.513.80.65
ZSW209644.526.741.25155.1181616.51.07
ZSW20976639.653186.42018212.08

Note:
3:1 factor of safety used, based on the ultimate load for underground use
5:1 factor of safety used, based on the ultimate load for overhead use

A note about dimensions and tolerances

Flexible Eye MU Revolving Eye Approx. breaking strength of cable grip (lb) Cable grip colour code Size range O.D. (in) Recommended swivel Safe working load of swivel at 3:1 (lb)
ZCS1710ZCS21777,000Dark green0.25 - 0.50ZSW20923,500
ZCS1711ZCS217810,500Brown0.50 - 0.75ZSW20935,000
ZCS1712ZCS217914,100Light blue0.75 - 1.00ZSW20935,000
ZCS1713ZCS218025,000Gold1.00 - 1.25ZSW209610,000
ZCS1714ZCS218131,000Black1.25 - 1.50ZSW209610,000
ZCS1715ZCS218231,000Red1.50 - 1.75ZSW209610,000
ZCS1716†ZSC2183*43,000-49,000Dark blue1.75 - 2.25ZSW209715,000

Note:
The above is intended as a rough guide. The recommended working load should be determined by the competent person(s) using the cable grip and/or Slingco swivel.

A note about dimensions and tolerances

Flexible Eye MU Revolving Eye Approx. breaking strength of cable grip (kN) Cable grip colour code" Size range O.D. (mm) Recommended swivel Safe working load of swivel at 3:1 (kN)
ZCS1710ZCS217731.1Dark green6 - 12ZSW209215.6
ZCS1711ZCS217846.7Brown12 - 19ZSW209322.2
ZCS1712ZCS217962.7Light blue19 - 25ZSW209322.2
ZCS1713ZCS2180111.2Gold25 - 32ZSW209644.5
ZCS1714ZCS2181137.9Black32 - 38ZSW209644.5
ZCS1715ZCS2182137.9Red38 - 44ZSW209644.5
ZCS1716†ZSC2183*191.3 - 218Dark blue44 - 57ZSW209766.7

Note:
The above is intended as a rough guide. The recommended working load should be determined by the competent person(s) using the cable grip and/or Slingco swivel.

A note about dimensions and tolerances
