Slingco Part No. | Colour Code | Range (mm) | Lattice Length (mm) | Min. Break Load (kg) | WLL (kg) |
---|---|---|---|---|---|
ZCS7229 | Green | 8 - 13 | 610 | 2,250 | 750 |
ZCS7230 | Brown | 12 - 19 | 610 | 3,380 | 1,127 |
ZCS7231 | Light Blue | 19 - 25 | 610 | 5,540 | 1,847 |
ZCS7232 | Gold | 25 - 32 | 610 | 9,550 | 3,183 |
Slingco Part No. | Colour Code | Range (in) | Lattice Length (in) | Min. Break Load (lb) | WLL (lb) |
---|---|---|---|---|---|
ZCS7229 | Green | 0.31 - 0.51 | 24 | 4,960 | 1,653 |
ZCS7230 | Brown | 0.47 - 0.75 | 24 | 7,452 | 2,484 |
ZCS7231 | Light Blue | 0.75 - 0.98 | 24 | 12,214 | 4,071 |
ZCS7232 | Gold | 0.98 - 1.26 | 24 | 21,054 | 7,018 |
The HD, MD and LD type form a range of conductor grips that are quick and easy to attach and remove, in s...
The HD, MD and LD type form a range of conductor grips that are quick and easy to attach and remove, in s...
The HD, MD and LD type form a range of conductor grips that are quick and easy to attach and remove, in s...
Our range is continually developing and expanding - plus we frequently undertake custom engineering design - so if you don’t see the exact product you need, please contact us with your exact requirements.
